1"×1/2" U-Bolt Mechanical Tee Orange Paint Coating Pipe Fitting UL/FM XGQT3US

OD:
33.7
42.4
48.3
60.3
73
76.1
OD2:
21.3
26.9
33.7
Quantity:
Contact Now
add to cart
UL/FM U-Bolt Mechanical Tee Orange XGQT3US
Approvals: UL certified , FM approved
Manufacturing Facility Standard: ISO 9001:2015 , GB/T19001-2016
Certification: Material Test Reports (MTRS) and Certificates of Conformity (COC) are available upon request.

grooved tee

Dimensions & Sizes

Nominal Size
mm/in		Pipe OD.
mm/in		Working
Pressure
psi/Mpa		Hole Dia.
Mm/in
+1.6,0/+0.063,0		Dimensions mm/inBolt Size
25×15
1×1/2		33.7*21.3
1.315*0.825		300 psi
2.07 Mpa		24
0.94		43
1.69		82
3.22		41
1.61		3/8*60-2
25×20
1×3/4		33.7*26.9
1.315*1.050		24
0.94		45
1.77		82
3.22		41
1.61		3/8*60-2
32×15
1-1/4×1/2		42.4*21.3
1.660*0.825		30
1.18		47
1.85		88
3.46		52
2.04		3/8*76-2
  32×20
1-1/4×3/4		42.4*26.9
1.660*1.050		30
1.18		49
1.93		88
3.46		52
2.04		3/8*76-2
32×25
1-1/4×1		42.4*33.7
1.660*1.315		30
1.18		51
2.00		88
3.46		52
2.04		3/8*76-2
40×15
1-1/2×1/2		48.3*21.3
1.900*0.825		30
1.18		50
1.96		88
3.46		52
2.04		3/8*76-2
  40×20
1-1/2×3/4		48.3*26.9
1.900*1.050		30
1.18		52
2.04		88
3.46		52
2.04		3/8*76-2
40×25
1-1/2×1		48.3*33.7
1.900*1.315		30
1.18		54
2.12		88
3.46		52
2.04		3/8*76-2
50×15
2×1/2		60.3×21.3
2.375×0.825		30
1.18		56
2.20		102
4.01		52
2.04		3/8*92-2
50×20
2×3/4		60.3×26.9
2.375×1.050		30
1.18		58
2.28		102
4.01		52
2.04		3/8*92-2
50×25
2×1		60.3×33.7
2.375×1.315		38
1.50		60
2.36		102
4.01		61
2.40		3/8*92-2
65×15
2-1/2×1/2		73.0×21.3
2.875×0.825		30
1.18		63
2.48		112
4.40		52
2.04		3/8*108-2
65×20
2-1/2×3/4		73.0×26.9
2.875×1.050		30
1.18		65
2.55		112
4.40		52
2.04		3/8*108-2
 65×25
 2-1/2 ×1		73.0×33.7
2.875×1.315		38
1.50		67
2.63		112
4.40		61
2.40		3/8*108-2
65×15
2-1/2×1/2		76.1×21.3
3.000×0.825		30
1.18		64
2.51		112
4.40		52
2.04		3/8*108-2
65×20
2-1/2×3/4		76.1×26.9
3.000×1.050		30
1.18		66
2.59		112
4.40		52
2.04		3/8*108-2
 65×25
 2-1/2 ×1		76.1×33.7
3.000×1.315		38
1.50		68
2.67		112
4.40		61
2.40		3/8*108-2
This innovative u bolt mechanical tee provides a reliable branch connection solution for fire protection and industrial piping systems. The versatile grooved tee design features a distinctive orange coating for easy identification and enhanced corrosion protection. UL/FM listed, this practical u bolt mechanical tee enables quick branch installations without special tools or pipe threading. The efficient grooved tee construction maintains pipe integrity while ensuring secure connections. Designed for sprinkler systems and process piping, this durable u bolt mechanical tee delivers exceptional performance in various environments. The precision-engineered grooved tee allows for flexible installation options and leak-proof operation, making it ideal for applications requiring efficient branch connections and long-term reliability in pressurized piping systems.
