3"×1" Threaded Concentric Reducer Orange Paint Coating Pipe Fitting UL/FM XGQT07S

OD:
42.4
48.3
60.3
73
76.1
88.9
108
114.3
133
139.7
141.3
159
165.1
168.3
219.1
OD2:
33.7
42.4
48.3
60.3
73
76.1
88.9
108
114.3
Quantity:
Contact Now
add to cart
UL/FM Threaded Concentric Reducer Orange XGQT07S
Approvals: UL certified , FM approved
Manufacturing Facility Standard: ISO 9001:2015 , GB/T19001-2016
Certification: Material Test Reports (MTRS) and Certificates of Conformity (COC) are available upon request.

threaded concentric reducer

Dimensions & Sizes

Nominal Size
mm/in		Pipe OD.
mm/in		Working
Pressure
psi/Mpa		Dimensions
L mm/in
32×25
1-1/4×1		42.4×33.7
1.660×1.315		300 psi
2.07 Mpa		64
2.51
40×32
1-1/2 ×1-1/4		48.3×42.4
1.900×1.660		64
2.51
50×25
  2×1		60.3×33.7
2.375×1.315		64
2.51
50×32
2×1-1/4		60.3×42.4
2.375×1.660		64
2.51
50×40
2×1-1/2		60.3×48.3
2.375×1.900		64
2.51
65×25
2-1/2×1		73.0×33.7
2.875×1.315		64
2.51
65×32
2-1/2×1-1/4		73.0×42.4
2.875×1.660		64
2.51
65×40
2-1/2×1-1/2		73.0×48.3
2.875×1.900		64
2.51
65×50
2-1/2×2		73.0×60.3
2.875×2.375		64
2.51
65×25
2-1/2×1		76.1×33.7
3.000×1.315		64
2.51
65×32
2-1/2×1-1/4		76.1×42.4
3.000×1.660		64
2.51
65×40
2-1/2×1-1/2		76.1×48.3
3.000×1.900		64
2.51
65×50
2-1/2×2		76.1×60.3
3.000×2.375		64
2.51
80×25
  3×1		88.9×33.7
3.500×1.315		64
2.51
80×32
3×1-1/4		88.9×42.4
3.500×1.660		64
2.51
80×40
3×1-1/2		88.9×48.3
3.500×1.900		64
2.51
80×50
3×2		88.9×60.3
3.500×2.375		64
2.51
80×65
3×2-1/2		88.9×76.1
3.500×3.000		64
2.51
100×25
4×1		108.0×33.7
4.250×1.315		76
2.99
100×32
4×1-1/4		108.0×42.4
4.250×1.660		76
2.99
100×40
4×1-1/2		108.0×48.3
4.250×1.900		76
2.99
100×50
4×2		108.0×60.3
4.250×2.375		76
2.99
100×65
4×2-1/2		108.0×76.1
4.250×3.000		76
2.99
100×80
4×3		108.0×88.9
4.250×3.500		76
2.99
100×25
4×1		114.3×33.7
4.500×1.315		76
2.99
100×32
4×1-1/4		114.3×42.4
4.500×1.660		76
2.99
100×40
4×1-1/2		114.3×48.3
4.500×1.900		76
2.99
100×50
4×2		114.3×60.3
4.500×2.375		76
2.99
100×65
4×2-1/2		114.3×76.1
4.500×3.000		76
2.99
100×80
4×3		114.3×88.9
4.500×3.500		76
2.99
125×25
5×1		133.0×33.7
5.250×1.315		89
3.50
125×32
5×1-1/4		133.0×42.4
5.250×1.660		89
3.50
125×40
5×1-1/2		133.0×48.3
5.250×1.900		89
3.50
125×50
5×2		133.0×60.3
5.250×2.375		89
3.50
125×25
5×1		139.7×33.7
5.500×1.315		89
3.50
125×32
5×1-1/4		139.7×42.4
5.500×1.660		89
3.50
125×40
5×1-1/2		139.7×48.3
5.500×1.900		89
3.50
125×50
5×2		139.7×60.3
5.500×2.375		89
3.50
125×65
5×2-1/2		139.7×76.1
5.500×3.000		89
3.50
125×80
5×3		139.7×88.9
5.500×3.500		89
3.50
125×100
5×4		139.7×114.3
5.500×4.500		89
3.50
125×25
  5×1		141.3×33.7
5.563×1.315		89
3.50
125×32
5×1-1/4		141.3×42.4
5.563×1.660		89
3.50
125×40
5×1-1/2		141.3×48.3
5.563×1.900		89
3.50
125×50
5×2		141.3×60.3
5.563×2.375		89
3.50
125×65
5×2-1/2		141.3×76.1
5.563×3.000		89
3.50
125×80
    5×3		141.3×88.9
5.563×3.500		89
3.50
150×25
  6×1		159.0×33.7
6.250×1.315		102
4.01
150×32
6×1-1/4		159.0×42.4
6.250×1.660		102
4.01
150×40
6×1-1/2		159.0×48.3
6.250×1.900		102
4.01
150×50
6×2		159.0×60.3
6.250×2.375		102
4.01
150×65
6×2-1/2		159.0×76.1
6.250×3.000		102
4.01
150×80
6×3		159.0×88.9
6.250×3.500		102
4.01
150×25
6×1		165.1×33.7
6.500×1.315		102
4.01
150×32
6×1-1/4		165.1×42
6.500×1.660		102
4.01
150×40
6×1-1/2		165.1×48.3
6.500×1.900		102
4.01
150×50
6×2		165.1×60.3
6.500×2.375		102
4.01
150×65
6×2-1/2		165.1×76.1
6.500×3.000		102
4.01
150×80
6×3		165.1×88.9
6.500×3.500		102
4.01
150×100
6×4		165.1×114.3
6.500×4.500		102
4.01
150×25
6×1		168.3×33.7
6.625×1.315		102
4.01
150×32
6×1-1/4		168.3×42.4
6.625×1.660		102
4.01
150×40
6×1-1/2		168.3×48.3
6.625×1.900		102
4.01
150×50
6×2		168.3×60.3
6.625×2.375		102
4.01
200×25
8×1		219.1×33.7
8.625×1.315		1275
200×32
8×1-1/4		219.1×42.4
8.625×1.660		1275
200×40
8×1-1/2		219.1×48.3
8.625×1.900		1275
200×50
8×2		219.1×60.3
8.625×2.375		1275
200×65
8×2-1/2		219.1×76.1
8.625×3.000		1275
200×80
8×3		219.1×88.9
8.625×3.500		1275
200×100
8×4		219.1×114.3
8.625×4.500		1275
This precision-engineered threaded concentric reducer provides reliable pipe size transitions in fire protection and industrial systems. The durable grooved reducer design features a distinctive orange paint coating for easy identification and enhanced corrosion protection. UL/FM listed, this versatile threaded concentric reducer ensures secure connections and optimal flow characteristics. The efficient grooved reducer construction allows for straightforward installation while maintaining system integrity. Designed for sprinkler systems and process piping, this robust threaded concentric reducer delivers excellent performance in demanding environments. The precision-machined grooved reducer guarantees perfect alignment and leak-proof operation, making it an ideal choice for applications requiring dependable pipe size reduction and long-lasting service life.
