    MSS-SP-114 Stainless Steel Threaded 90° Reducing Elbow

    Thread Type:
    NPT
    Size:
    1/4"x1/8"
    3/8"x1/8"
    3"x2"
    3/8"x1/8"
    1/2"x1/8"
    1/2"x1/4"
    1/2"x3/8"
    3/4"x1/4"
    3/4"x3/8"
    3/4"x1/2"
    1"x1/4"
    1"x3/8"
    1"x1/2"
    1"x3/4"
    1-1/4"x3/8"
    1-1/4"x1/2"
    1-1/4"x3/4"
    1-1/4"x1"
    1-1/2"x3/8"
    1-1/2"x1/2"
    1-1/2"x3/4"
    1-1/2"x1"
    1-1/2"x1-1/4"
    2"x1/2"
    2"x3/4"
    2"x1"
    2"x1-1/4"
    2"x1-1/2"
    2-1/2"x1/2"
    2-1/2"x3/4"
    2-1/2"x1"
    2-1/2"x1-1/4"
    2-1/2"x1-1/2"
    2-1/2"x2"
    3"x1"
    3"x1-1/4"
    3"x1-1/2"
    3"x2-1/2"
    4"x1-1/4"
    4"x1-1/2"
    4"×2"
    4"×2-1/2"
    4"x3"
    Pressure Ratings:
    150 lbs
    Material：:
    304
    304L
    316
    316L
    Custom
    Quantity:
    Contact Now
    add to cart
    MSS SP-114 90° Reducing Elbow
    Standard: ANSI/MSS SP-114
    Threads Standard: ASME B1.20.1
    Cast Stainless Steel Material Standard: ASME A351, GB/T 2100, EN 10213, JIS G5121
    Manufacturing Facility Standard: ISO 9001:2015 , GB/T19001-2016
    Certification: Material Test Reports (MTRS) and Certificates of Conformity (COC) are available upon request.

    Product Overview

    The Reducing Threaded Elbow 304 Stainless Steel Pipe Fitting is designed to change flow direction while connecting pipes of different diameters. By combining size transition and directional change in a single fitting, it helps simplify piping layouts, reduce joint count, and improve overall system efficiency. Suitable for industrial, commercial, and residential applications, this fitting provides reliable performance with secure threaded connections.

    Key Features

    • Premium 304 Stainless Steel：Manufactured from high-grade SS304 stainless steel, offering excellent corrosion resistance, rust prevention, and long-term durability in demanding environments.
    • Reducing Elbow Design：Enables smooth directional change while transitioning between different pipe sizes, minimizing the need for additional fittings.
    • Precision Threaded Connection：Accurately machined threads ensure a tight, leak-resistant connection with standard threaded piping systems.
    • Cast Construction：Cast body provides consistent wall thickness and structural stability for reliable performance.
    • 150lb Pressure Rating：Rated for Class 150 working pressure, suitable for low to medium pressure piping systems.
    • Wide Media Compatibility：Suitable for water, gas, oil, air, and other non-corrosive fluids.

    Dimensions & Sizes

    reducing street elbow

    SizeT1xT2DNφDφD1ab
    1/4"x1/8"8x61814.51818
    3/8"x1/8"10x62114.51920
    3/8"x1/4"10x821182022
    1/2"x1/8"15x626.514.52322
    1/2"x1/4"15x826.5182424
    1/2"x3/8"15x1026.5212625
    3/4"x1/4"20x832182627
    3/4"x3/8"20x1032212628
    3/4"x1/2"20x153226.52930
    1"x1/4"25x839.5182635.5
    1"x3/8"25x1039.5213131.5
    1"x1/2"25x1539.526.53233
    1"x3/4"25×2039.5323435
    1-1/4"x3/8"32x1048.5213439
    1-1/4"x1/2"32x1548.526.53439
    1-1/4"x3/4"32x2048.5323740
    1-1/4"x1"32x2548.539.54042
    1-1/2"x3/8"40x1055213542
    1-1/2"x1/2"40x155526.53542
    1-1/2"x3/4"40x2055323843
    1-1/2"x1"40x255539.54145
    1-1/2"x1-1/4"40x325548.54548

    tolerance：1/8"~2"ab-0.6mm、2-1/2"~4"ab-1.2mm
